Denis Cimaf DAF-180E Skid Steer Mounted Mulching Attachment - for 125 HP Forestry Carriers

The Denis Cimaf DAF-180E Skid Steer Mounted Mulching Attachment is a powerful forestry brushcutting and mulching system designed for carriers with approximately 125 hp. Engineered for vegetation control and land clearing applications, this attachment features Denis Cimaf’s patented high-speed rotor technology for efficient cutting and reliable performance. With a durable design and wide cutting path, the DAF-180E is ideal for forestry contractors, land management professionals, and vegetation control crews.

KEY FEATURES

• DESIGNED FOR 125 HP FORESTRY CARRIERS: Optimized for compact loaders and forestry carriers with approximately 125 hp (95 kW), providing reliable mulching performance in demanding environments.
• PATENTED HIGH-SPEED ROTOR TECHNOLOGY: Advanced rotor design improves efficiency and cutting performance, allowing operators to process vegetation quickly and effectively.
• 74 IN (188 CM) CUTTING WIDTH: Wide cutting path allows operators to clear vegetation efficiently while maintaining excellent maneuverability in forestry environments.
• 27 FIXED KNIVES: Durable fixed knives deliver aggressive cutting power for brush, shrubs, and small trees.
• 170CC VARIABLE DISPLACEMENT HYDRAULIC MOTOR: High-torque hydraulic motor provides consistent power and dependable mulching performance.
• BOLT-ON REPLACEABLE WEAR LINER: Protects internal components from excessive wear and allows easy replacement for extended equipment lifespan.
• NO-SLIP TIMING BELT: Ensures efficient power transfer and reliable rotor operation during heavy cutting tasks.
• SPARE SET OF KNIVES INCLUDED: Provides convenient blade replacements to reduce downtime and maintain cutting efficiency.
• BRUSHCUTTER MAINTENANCE KIT: Includes essential tools to maintain blade sharpness and ensure consistent mulching performance.
• GAS-POWERED FILING TOOL: Allows operators to sharpen knives directly on-site, minimizing downtime and maintaining productivity.
• STANDARD SKID STEER MOUNTING BRACKETS: Enables quick and easy attachment to compatible skid steer loaders.
• HEAVY-DUTY STATIONARY PUSH BAR: Improves vegetation handling and enhances operator control when cutting dense brush and trees.

APPLICATIONS / USE CASES

• FORESTRY MULCHING: Clears dense vegetation, brush, and small trees in forestry and land management applications.
• LAND CLEARING: Ideal for preparing land for construction, agriculture, and infrastructure projects.
• RIGHT-OF-WAY MAINTENANCE: Efficiently manages vegetation along utility corridors, roadsides, and pipelines.
• VEGETATION MANAGEMENT: Helps control invasive species and overgrown vegetation in large areas.

WHAT’S INCLUDED

• Denis Cimaf DAF-180E Mulching Attachment
• One Spare Set of Knives
• Brushcutter Maintenance Kit
• Gas-Powered Filing Tool
• User Manual

OPTIONAL ACCESSORIES

• Hydraulic Pushbar (44440FORY) - Hydraulic Hoses Not Included

TECHNICAL SPECIFICATIONS

• MINIMUM CARRIER POWER: 125 HP (95 kW)
• CUTTING WIDTH: 74 in (188 cm)
• CUTTING DISTANCE FROM GROUND: 0.8 in (2 cm)
• NUMBER OF ROTOR BLADES: 27
• OPTIMAL TARGET MATERIAL DIAMETER: 10 in (25 cm)
• ROTOR DIAMETER: 20 in (51 cm)
• EXTERIOR WIDTH: 88 in (223 cm)
• EXTERIOR HEIGHT (WITH PUSHBAR): 55 in (139 cm)
• EXTERIOR HEIGHT (WITHOUT PUSHBAR): 37 in (94 cm)
• EXTERIOR DEPTH (WITH PUSHBAR): 45 in (114 cm)
• EXTERIOR DEPTH (WITHOUT PUSHBAR): 27 in (69 cm)
• WEIGHT: Approx. 3300 lb (1497 kg)

HYDRAULIC SYSTEM SPECIFICATIONS

• HYDRAULIC MOTOR: 1 × Variable Displacement Axial Piston Motor
• DISPLACEMENT: 170 cc
• MAX CYLINDERS: 170
• MAX MOTOR TORQUE: 502 lb-ft (681 Nm)
• REQUIRED CONTINUOUS FLOW: 50 gal/min (189 L/min)
• OPERATING PRESSURE: 6000 psi (414 bar)
• ROTATING SPEED: 2400 rpm
• PRESSURE LINE I.D.: 1 in (#16)
• RETURN LINE I.D.: 1 in (#16)
• DRAIN LINE I.D.: 0.675 in (#10)

FREQUENTLY ASKED QUESTIONS (FAQ)

1. What carrier power is required for the DAF-180E?
It is designed for forestry carriers with approximately 125 hp (95 kW).

2. What is the cutting width?
The mulcher provides a 74 in (188 cm) cutting width for efficient vegetation clearing.

3. What size material can it handle?
The optimal target material diameter is approximately 10 in (25 cm).

4. Does it include maintenance tools?
Yes, it includes a spare set of knives, a brushcutter maintenance kit, and a gas-powered filing tool for sharpening blades on-site.

5. What hydraulic flow is required?
The attachment requires approximately 50 gal/min (189 L/min) of continuous hydraulic flow.
