Denis Cimaf DAH-150ER Excavator Mounted Mulching Attachment - for 27 to 35 Ton Excavators

The Denis Cimaf DAH-150ER Excavator Mounted Mulching Attachment is a high-power forestry brushcutting and mulching system designed for heavy-duty vegetation control and land clearing. Engineered for excavators ranging from 27 to 35 tons, the DAH mulching system utilizes Denis Cimaf’s patented high-speed rotor technology to efficiently process dense brush, trees, and vegetation. Built for durability and productivity, this excavator-mounted mulcher is ideal for forestry operations, right-of-way maintenance, and large-scale land management projects.

KEY FEATURES

• DESIGNED FOR 27 TO 35 TON EXCAVATORS: Optimized for excavators ranging from 54,000 to 70,000 lb (24.5–32 t), providing powerful mulching performance for demanding forestry applications.
• PATENTED HIGH-SPEED ROTOR TECHNOLOGY: Advanced rotor design delivers high cutting efficiency and superior productivity in dense vegetation.
• 57 IN (145 CM) CUTTING WIDTH: Provides excellent coverage while maintaining maneuverability for excavator-mounted operations.
• 21 FIXED KNIVES: Heavy-duty knife configuration delivers aggressive cutting performance for brush, trees, and dense vegetation.
• 170CC VARIABLE DISPLACEMENT HYDRAULIC MOTOR: High-performance hydraulic motor provides consistent torque and reliable mulching capability.
• HEAVY DUTY HYDRAULIC DOOR: Limits debris projection and improves safety during mulching operations.
• NO-SLIP TIMING BELT: Ensures dependable power transfer and efficient rotor operation in demanding conditions.
• BRUSHCUTTER MAINTENANCE KIT INCLUDED: Provides essential tools required for maintaining optimal cutting performance.

APPLICATIONS / USE CASES

• FORESTRY MULCHING: Efficiently clears trees, brush, and dense vegetation in forestry environments.
• RIGHT-OF-WAY MAINTENANCE: Ideal for maintaining vegetation along power lines, pipelines, and roadways.
• LAND CLEARING: Prepares land for construction, agriculture, and development projects.
• VEGETATION MANAGEMENT: Helps control invasive species and overgrown areas in large outdoor environments.

WHAT’S INCLUDED

• Denis Cimaf DAH-150ER Excavator Mounted Mulching Attachment
• Brushcutter Maintenance Kit
• User Manual

OPTIONAL ACCESSORIES

• Blank Top Plate (D122 007RY)
• Tilt System (D132 514ARY)
• Standard pin-on mounting bracket/Pin Grabber (includes pins)

TECHNICAL SPECIFICATIONS

• EXCAVATOR SIZE: 54,000-70,000 lb (24.5-32 t)
• APPROX. CARRIER POWER: 192 HP (143 kW) and up
• CUTTING WIDTH: 57" (145 cm)
• CUTTING DISTANCE FROM GROUND LEVEL: 1.07" (2.7 cm)
• NUMBER OF BLADES ON ROTOR: 21
• TARGET MATERIAL DIAMETER: 20" (51 cm)
• EXTERIOR LENGTH: 78" (198 cm)
• HEIGHT: 43" (109 cm)
• WIDTH: 32" (81 cm)
• ROTOR DIAMETER: 20" (51 cm)
• WEIGHT, TYPICAL (ESTIMATED): 3700 lb (1678 kg)
• WEIGHT, WITH ALL OPTIONS: 4640 lb (2105 kg)

HYDRAULIC SPECIFICATIONS

• MOTOR MX CYL. (CC): 170
• REQUIRED CONTINUOUS FLOW*: 55 gal/min (208 L/min)
• OPERATING PRESSURE (PSI) - UP TO*: 6000
• OPTIMAL ROTATING SPEED (RPM): 3000
• PRESSURE LINE I.D.: 1.25" (#20)
• RETURN LINE I.D.: 1.25" (#20)
• DRAIN LINE: .75" (#12)

FREQUENTLY ASKED QUESTIONS (FAQ)

1. What excavator size is required for the DAH-150ER?
The mulcher is designed for excavators between 27 and 35 tons (54,000–70,000 lb).

2. What is the cutting width?
The mulcher provides a 57 in (145 cm) cutting width for efficient vegetation clearing.

3. What size material can it handle?
The mulcher is designed to process vegetation and trees up to approximately 20 in (51 cm) in diameter.

4. What hydraulic flow is required?
The attachment requires approximately 55 gal/min (208 L/min) of continuous hydraulic flow.

5. Does it include maintenance tools?
Yes, a brushcutter maintenance kit is included to help maintain cutting performance.
